Description
Samples collected via cervical brushing are purified using gradient centrifugation, effectively removing impurities.
The XJ-6 Cell Smear Centrifuge then processes diagnostic components like cells and bacteria into a flat, uniform layer, free from overlaps.
These ultra-thin layers adhere to glass slides, ready for microscopic examination or computer analysis. With the capacity to process 12 samples in just 5 minutes, it combines user-friendly operation, eco-friendly design, and consistent cell layering, even on a clear background.
Specifications:
| Speed range(rpm) | 0-1200rpm adjustable | Noise(dBA) | ≦55 dB(A) |
| Control | Microprocessor control | Motor | Inverter motor direct drive |
| Max Capacity(ml) | 12 cell slide clips | Height of Cell Slide Clips | 50mm |
| Time Range | 0-99min | Dimension(mm) | 440*400*230mm |
| RCF range (xg) | 0-241xg adjustable | Net weight(without rotor) | 22KG |
| Power supply | AC220V,50HZ,5A,60W | ||
Features
The centrifuge features a metal housing, metal lid, and stainless steel centrifuge chamber, all autoclave-able and resistant to detergents and disinfection liquids.
Controlled by a microprocessor with a frequency conversion A.C. motor drive for precision operation.
The LED display shows various parameters such as speed, timer, RCF, rotor programs (memory), acceleration, deceleration information, and error codes.
To ensure a secure seal, the centrifuge is designed with a double-layer sealing ring for both the lid and the instrument.
Enhanced bio-safety measures include a gas-tight rotating head
sterilizable at high temperatures and a centrifugal cavity with
ultraviolet sterilization function. The centrifuge enters
sterilization mode upon startup.
Matched Rotor
| No. | Rotor | Capacity | Max. speed | Max. RCF | Note |
NO.1
| Swing rotor | 12 cell slide clips | 1200r/min | 241xg | Swing rotor of settlement type |
