Hunan Michael Laboratory Instrument Co.,Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | MKE |
| Model Number : | VCK-22R |
| Certification : | CE,ISO13485,ISO9001,SFDA |
| Price : | Negotiable |
| Delivery Time : | 7-15 work days |
| Payment Terms : | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability : | 100 set/month |
Technical Specifications:
Max. Speed | 22000rpm | Motor | AC frequency conversion motor, direct drive |
Speed accuracy | ±10rpm | Screen | Touch LCD color+digital screen |
Max.Capacity | 6x250ml | Control | advanced CPU control system |
Max. RCF | 41495xg | Timer range | 1~99min59s |
The refrigerant | R-22 | Temp accuracy | ±1℃ |
Temp.range (at RT 25℃) | -20℃~40℃ | Acceleration/Deceleration Rate | 10 |
Noise | ＜60dB(A) | Power supply | AC220v 50Hz 30A,3kw |
Net weight | 240kg | Dimension | 690x590x820mm(L×W×H) |
Gross weight | 280kg | Packing Size | 920×790×1700mm(L×W×H) |
Matched Rotors:
No. | Rotor | Capacity | Max.speed | Max. RCF | Note |
NO.1
| Fixed Angle Rotor | 12×5ml | 22000r/min | 37877xg | PP/PC tube |
NO.2
| Fixed Angle Rotor | 24x1.5ml | 20000r/min | 41495xg | PP/PC tube |
NO.3
| Fixed Angle Rotor | 16x10ml | 18000r/min | 34835xg | PP/PC tube |
NO.4
| Fixed Angle Rotor | 12x15ml | 17000r/min | 34835xg | PP/PC tube |
NO.5
| Fixed Angle Rotor | 6×50ml | 18000r/min | 34777xg | PP/PC tube |
NO.6
| Fixed Angle Rotor | 8x50ml | 16000r/min | 30395xg | PP/PC tube |
NO.7
| Fixed Angle Rotor | 6×100ml | 16000r/min | 30395xg | PP/PC tube |
NO.8
| Fixed Angle Rotor | 4x250ml | 13000r/min | 26039xg | PP/PC tube |
NO.9
| Fixed Angle Rotor | 6×250ml | 10000r/min | 8721xg | PP/PC tube |
Features:
High power AC frequency conversion motor winding indirect drive, small vibration, low noise, long service life.
Microcomputer control, colour screen display, programmable and storable, speed, centrifugal force, time can be displayed at the same time.
Six levels of damping damping, centrifugal effect to achieve the best, 10 kinds of lift speed curve, 30 kinds of free program can be programmed and stored, can meet different experimental needs.
Door cover, body configuration double silicone sealing ring, sealing performance is particularly good, long-term use does not aging, not deformation.
"Mute" patented technology, the maximum speed is less than 60dB.
Rotor automatic locking function, no need to tighten the rotor head, rotor automatic identification system, to prevent the wrong rotor running, effectively protect the safety of personnel and the stability of the centrifuge.
Multi-level protection functions such as over-speed,
over-temperature, imbalance, electronic safety door lock, etc. are
provided to ensure the safety of human and machine.
WHY CHOOSE US
Our Factory Introduction
We have a standardized production workshop operated by a dedicated
team that ensures quality in every laboratory centrifuge and lab
equipment we produce. Our R&D division includes design
engineers, technology specialists, qualified experts, and process
control managers. Following a strict quality control system, our
specialists oversee the entire production process, from design and
R&D to testing, production, quality inspection, and packaging.
Specialize in centrifuges.
With decades of experience, we've exported to 80+ countries.
Proven Reputation: SGS and Intertek inspected, underlining our
reliablity.
Manufacturing Capabilities: 6 floors, 3000 sqm each, dedicated to
manufacturing and quality control.
MKE Exhibition
Packaging & Delivery
MKE centrifuges are securely packaged in wooden cases or carton boxes, selected according to the weight and size of the goods. This ensures they are delivered in excellent condition to customers worldwide.
After-Sale WARRANTY
FAQ
|
|
