Hunan Michael Laboratory Instrument Co.,Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | MKE |
| Model Number : | TGL-16M |
| Certification : | CE,ISO13485,ISO9001,SFDA |
| Price : | Negotiable |
| Delivery Time : | 7-15 work days |
| Payment Terms : | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability : | 100 set/month |
Benchtop High Speed Refrigerated Centrifuge 16500rpm Lab Centrifuge
Description:
The high-speed refrigerated centrifuge TGL-16M stands out with its impressive maximum speed of 16,500 rpm. Its built-in refrigeration feature ensures precise temperature control during the separation process, crucial for preserving sample integrity. Compatible with a range of fixed-angle rotors and adapters, it caters to high-speed centrifugation needs spanning volumes from 0.2ml to 100ml. Despite its robust capabilities, its compact design makes it a perfect fit for labs with limited space, combining efficiency and convenience seamlessly.
Technical Specifications:
Max. RPM | 16,500rpm | Speed accuracy | ±10r/min |
Max.Capacity | 4 x100ml | Temp. Range | -20 °C ~ 40°C |
Max.RCF | 23120xg | Temperature control accuracy | ±1℃ |
Time control | 1-99minutes 59s adjustable | ACC/DEC | 10/10 steps |
Noise level (dB) | ≦58dB(A) | Program memory | 30 |
Display | LCD | Weight without rotor (kg) | 70 kg |
Dimension (W x D x H, mm) | 600x570x380mm(LxWxH) | Power supply | AC220V,50HZ,10A; 880W |
Matched Rotors(Customized rotors are available)
No. | Item | Max. capacity | Max.speed | Max.RCF | Note |
NO.1 | Angle rotor | 12×1.5/2.2ml | 16500r/min | 19176xg | PP/PC tube |
Adapter | 12×0.5ml | PP/PC tube | |||
Adapter | 12×0.2ml | PP/PC tube | |||
NO.2 | Angle rotor | 12×5ml | 16500r/min | 19480xg | PP/PC tube |
Adapter | 12×1.5ml | PP/PC tube | |||
NO.3 | Angle rotor | 12×10ml | 12000r/min | 13523xg | PP/PC tube |
Adapter | 12×5ml | PP/PC tube | |||
NO.4 | Angle rotor | 24×1.5/2.2ml | 14000r/min | 18407xg | PP/PC tube |
Adapter | 24×0.5ml | PP/PC tube | |||
Adapter | 24×0.2ml | PP/PC tube | |||
N0.5 | Angle rotor | 36×1.5/2.2ml | 13000r/min | 15304xg | PP/PC tube |
Adapter | 36×0.5ml | PP/PC tube | |||
Adapter | 36×0.2ml | PP/PC tube | |||
NO.6 | Angle rotor | 12×8×0.2ml | 12000r/min | 16985xg | PCR 8-tube strips |
NO.7 | Angle rotor | 10×15ml | 11000r/min | 14069xg | PP/PC tube |
Adapter | 10×10ml | PP/PC tube | |||
Adapter | 10×5ml | PP/PC tube | |||
NO.8 | Angle rotor | 6×50ml | 11000r/min | 13122xg | PP/PC tube |
Adapter | 6×15ml | PP/PC tube | |||
Adapter | 6×10ml | PP/PC tube | |||
Adapter | 6×1.5ml | PP/PC tube | |||
NO.9 | Angle rotor | 4×10/100ml | 10000r/min | 10733xg | PP/PC tube |
Adapter | 4×50ml | PP/PC tube | |||
Adapter | 4×15ml | PP/PC tube | |||
Adapter | 4×10ml | PP/PC tube | |||
Adapter | 4×5ml | PP/PC tube | |||
Adapter | 4×1.5ml | PP/PC tube |
Features:
Direct Drive AC Variable Frequency Motor: Experience high
precision, low noise, and an extended lifespan for reliable and
efficient operation.
High-Efficiency and Environmentally Friendly Refrigeration System:
Our centrifuge adopts an advanced cooling system that not only
ensures precise temperature control but also eliminates
environmental pollution.
Silent Technology and "Low-Noise" Patent Certification: With our
innovative "Low-Noise" technology, enjoy a quiet laboratory
environment as the centrifuge operates at a maximum noise level
below 58 decibels.
Microcomputer Control and Color LCD Display: Take full control of
your experiments with ease. Our centrifuge's user-friendly
interface allows programming, storage, and simultaneous display of
speed, centrifugal force, and time on a vibrant color screen.
10 adjustable lift speed curves. Customize up to 30 programmable
and storable free programs to meet your diverse experimental needs.
Double-Layer Sealing Rings on the Door Cover and Body: Designed to
meet the demands of long-term use, our centrifuge features
excellent sealing performance, ensuring airtight operation.
Three-Level Damping System and Versatile Speed Curves: Experience
optimal stability and versatility with our centrifuge's three-level
damping system.
Multiple Safety Features: We prioritize safety. Our centrifuge is equipped with multiple layers of protection, including overspeed detection, overheating prevention, and an electronic safety door lock, ensuring the well-being of both the user and the machine.
WHY CHOOSE US
Our Factory Introduction
We have a standardized production workshop operated by a dedicated
team that ensures quality in every laboratory centrifuge and lab
equipment we produce. Our R&D division includes design
engineers, technology specialists, qualified experts, and process
control managers. Following a strict quality control system, our
specialists oversee the entire production process, from design and
R&D to testing, production, quality inspection, and packaging.
Specialize in centrifuges.
With decades of experience, we've exported to 80+ countries.
Proven Reputation: SGS and Intertek inspected, underlining our reliablity.
Manufacturing Capabilities: 6 floors, 3000 sqm each, dedicated to
manufacturing and quality control.
MKE Exhibition
Packaging & Delivery
MKE centrifuges are securely packaged in wooden cases or carton boxes, selected according to the weight and size of the goods. This ensures they are delivered in excellent condition to customers worldwide.
After-Sale WARRANTY
FAQ
|
|
